Connection: CCP Channels: 4
Gain: 0, 20, 40 dB

Connection: Traditional 200 V / CCP
Channel(s): 2

Connection: CCP
Channel(s): 1

Connection: Traditional 200 V
Channel(s): 10

Connection: Traditional 200 V
Channel(s): 1

Connection: Traditional 200 V
Channel(s): 6

Connection: Traditional 200 V / CCP
Channel(s): 1

Self Insertion Loss: >25 dB
CCP Microphone set

ITU-T rec.: P. 64

IEC 60318 or IEC 60711 depending on configuration

ANSI: S12.42

ITU-T rec.: P. 64

IEC 60318-1 ear simulators
IEC 60318-4 ear simulators
Human-llike pinna
Easy in situ calibration

ISO: 4869-3
IEC: 60318-1 and 60318-4
depending on configuration

Freq range: 10 Hz to 16 kHz
Dyn range: 6.5 dB(A) to 110 dB
Sensitivity: 850 mV/Pa
Measures incl. feet: Diagonal 4716 mm Height 2283 mm

Freq range: 10 Hz to 16 kHz
Dyn range: 6.5 dB(A) to 110 dB
Sensitivity: 850 mV/Pa
Measures incl. feet: Diagonal 2716 mm Height 1283 mm

Freq range: 3.15 Hz to 20 kHz
Dyn range: 17 dB(A) to 149 dB
Sensitivity: 50 mV/Pa
Measures incl. feet: Diagonal 4716 mm Height 2283 mm

Freq range: 3.15 Hz to 20 kHz
Dyn range: 17 dBA to 149 dB
Sensitivity: 50 mV/Pa
Measures incl. feet: Diagonal 2716 mm Height 1283 mm
